SINGLE PHASE TRANSFORMER LAB

EE-8133

Single Phase Transformer Lab is an elite training system for the Electrical laboratories. The product helps you to get fully acquainted with the basic concepts and functioning of a Single Phase Transformer.

The product is represented in such an easy way that each test can be studied differently in proper sequence. The Lab practically expertise you in exercises like Polarity, Turns Ratio.

Transformation Ratio, Iron Loss, Copper Loss, Efficiency etc. The vast scope of learning makes the subject easily and completely understandable.

FEATURES:-

  • Inbuilt Single Phase
  • Equipped with Supply Indication Lamp
  •  Facility to use Fixed and Variable Load
  •  Control board consist of high grade FRP material to provide utmost safety to the users
  •  Terminals provided to use the optional externally
  •  Designed by considering all the safety standards
  •  Diagrammatic representation for the ease of connections
  •  Flexibility to configure Step-up, Step-down and Isolation Transformer
  •  Exclusive and Compact Design
  •  Product Tutorial (CD)

TECHNICAL SPECIFICATIONS:

  •  Mains Supply : Single Phase, 230V AC ±10%, 50Hz
  •  Single Phase Transformer
  •  Rating : 1kVA
  •  Primary Voltage : 0-125V, 0-125V
  •  Secondary Voltage : 0-125V, 0-125V
  •  Rated Current : 4A
  •  Single Phase Auto Transformer
  •  Primary Voltage : 230V
  •  Secondary Voltage : 0-270V
  •  Rated Current : 5A
  •  Digital Meters Used
  •  AC Voltmeter : 450V (2nos.)
  •  AC Ammeter : 5A (2nos.)
  •  Wattmeter : 1500W
