MICROPROCESSOR DISINTEGRATION TEST APPARATUS

PCE-A33

Features:

  • Complies with USP, IP specifications
  • Extremely useful for pharmaceutical labs
  • Highly Accurate and Easy to Operate
  • Baskets & DOWN movement as per IP/USP

Specifications :

  • 20 x 4 Line Alphanumeric LCD with Backlit
  • 15 Soft Touch Membrane Type Keys
  • 20 Setups Storage Facility
  • 200 Samples Storage Facility
  • Printer Attachment Facility
  • Audio Visual Indicators for System Status.

Specifications :

Display  20 x 4 line alphanumeric LCD display with backlit
Keyboard 15 soft touch membrane keys
 LED’s 3 LED’s for Test status like Run, Alarm, End and one LED for heater on/off status.
Setup Data Facility for 20 different test setups available
Printer  Provision for the attachment of dot-matrix printer
Speed 55 mm. 30 ± 1 strokes per minute
Resolution  1 Sec – 99 Minutes
 Temp. Range 20 °C – 40 °C
Temp. Accuracy ± 0.2 °C
Temp. Control  Microprocessor based using PT100/Semiconductor Sensor
 Reaction Beaker  1000 ml
 Heater 1 KW
 Power  230 V ± 10% AC, 50 Hz

Accessories:

  • Main Unit with Acrylic Tank and Rectangular Cover Plate
  • Reaction Vessel – capacity 1000 ml – 2 Nos.
  • Two USP Baskets with 6 Tubes and 6 guided Discs, each
  • External Temperature Sensor
  • Mains Lead
  • Instruction Manual
  • Dust Cover
